Accessories Accessories
Accessorie
Blanking plate Stack assembly
Linking plate
• p = 350 bar NG10 NG3-Mini ®
max
ISO 4401-05
DESCRIPTION APPLICATION Ø 6,5 SOCKET hEad CaP SCREW M4xL STUd M4xL STEP NUT M4 art. Nr. 154.7404
Blanking and linking plates NG10 acc. to ISO Blanking plates are used to seal all ports (P, A,
4401-05. The plates are zinc coated and will B, T, T0) of a NG10 interface. With linking plates s 3 M4
be supplied inclusive 5 O-rings ID 14,00x1,78 selected ports of a NG10 interface can be con- M4 M4 Ø 7
(article 160.2140). The connections T and To nected. Other ports not in use are sealed. s 9
are connected together.
30
16 7 4 6
L L 10
TYPE CODE
88
A BP 10 #
A U 10 / # FIXaTION WITh SOCKET hEad CaP SCREWS
Effective stack length description and dimension ( M4xL ) Fastening torque article No.
International standard interface ISO P
38 ... 40 Cap screw M4x45 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1146
Blanking plate BP A B 16,8 43 ... 45 Cap screw M4x50 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1151
Linking plate U
60 46 48 ... 50 Cap screw M4x55 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1156
T To 9,7
Nominal size 10 1,5 53 ... 55 Cap screw M4x60 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1161
56 ... 58 Cap screw M4x63 Steel 8.8 zinc coated 2,6 Nm 249.1007
Connection of ports see type code list and symbols 58 ... 60 Cap screw M4x65 Steel 12.9 black DIN 912 5 Nm 246.1365
61 ... 63 Cap screw M4x68 Stee l 8.8 zinc coated 2,6 Nm 249.1005
Design-Index (Subject to change)
20,8 63 ... 65 Cap screw M4x70 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1171
48 68 ... 70 Cap screw M4x75 Steel 8.8 zinc coated 2,6 Nm 249.1004
54 73 ... 75 Cap screw M4x80 Steel 8.8 zinc coated DIN 912 2,6 Nm 246.1181
DIMENSIONS TYPES
Blanking and linking plate Types Article no. Symbols
Blanking plate: FIXaTION WITh STUdS aNd STEP NUTS
Ø 6,5
ABP10 173.4150 A P T B Effective stack length description and dimension ( M4xL ) Fastening torque article No.
Linking plate: 52 ... 60 Stud M4x73 St 329 black 2,8 Nm 224.1006
84 ... 92 Stud M4x105 St 329 black 2,8 Nm 224.1007
AU10 / P-B / A-T 173.4250 93 ... 101 Stud M4x114 St 329 black 2,8 Nm 224.1009
30 A P T B
115 ... 123 Stud M4x136 St 329 black 2,8 Nm 224.1005
AU10 / P-A / B-T 173.4251 146 ... 154 Stud M4x167 St 329 black 2,8 Nm 224.1004
A P T B
AU10 / P-A 173.4252 Effective stack length = Length between head of screw and top of base plate
A P T B
88
AU10 / P-B 173.4253
A P T B
AU10 / P-T 173.4254
P A P T B
AU10 / A-T 173.4255
A B 16,8 A P T B
60 46
T To 9,7 AU10 / B-T 173.4256
1,5 A P T B
AU10 / A-B-T 173.4260
A P T B
AU10 / A-B 173.4257
20,8 A P T B
48 AU10 / P-A-B 173.4258
54 A P T B
Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no. Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.10-140E 1/1 Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.10-210E 1/1
CH-3714 Frutigen Edition 12 10 CH-3714 Frutigen Edition 10 21
