Accessories
Accessorie

Threaded ports sandwich body
• p max = 350 bar NG6
ISO 4401-03

DESCRIPTION APPLICATION
Sandwich bodies NG6 according to ISO 4401- Threaded ports sandwich bodies in stacking
03 with ports G3/8" for external connection to A systems to connect gauges, sensors or control
and B or P and T lines. Sandwich bodies with elements.
one external connection (A, B, P, T) will have
the second port plugged with plug G3/8" (arti-
cle 238.3402). The sandwich bodies are zinc
coated and will be supplied inclusive 4 O-rings
ID 9,25x1,78 (article no. 160.2093).

TYPE CODE
A SGK 6 #

International standard interface ISO
Sandwich threaded body

Type list / Function
in A A in P P
in B B in T T
in A and B AB in P and T PT

Nominal size 6
Design-Index (Subject to change)

TYPES DIMENSIONS
Ø 5,5
ASGKA6 Ø 5,5
A P T B
(article 203.3501)
A P T B 40 G 3/8"
20
40 G 3/8"
ASGKB6
B
P T
A (article 203.3502)
20
A P T B 40,5
17,8
ASGKAB6 40,5 ASGKA, B, AB6
P T
B
A (article 203.3500) 17,8
T
A P T B A B
T 45 A 31 B 32,5
ASGKP6 A B 22,5 P
45
A
22,5 T
P
A (article 203.3504) 31 B B 32,5
A P T B P 60 120
60
ASGKT6 120
(article 203.3505) ASGKP, T, PT6
A P T B
T
A P T B T
T 8 A B
ASGKPT6 T P 8
(article 203.3503) A B P
8
A P T B P 8
P
A P T B
Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.10-30E 1/1
CH-3714 Frutigen Edition 13 25
