Proportional flow control valves
Proportional flow control valve

Proportional 3-way flow control valve
Screw-in cartridge
• Direct operated, pressure compensated M42 x 2
• Q max = 200 l/min, p max = 350 bar ISO 7789
• Q N max = 160 l/min

DESCRIPTION FUNCTION APPLICATION
Direct operated, pressure compensated pro- The 3-way flow control valve serves for maintai- Proportional flow control valves are suitable for
portional flow control valve as a screw-in cart- ning the speed of a consumer constant inde- feed control systems, where the consumer flow
ridge with a thread M42 x 2 for cavity acc. to pendent of the load. Superfluous pump output has to be maintained constant with a changing
ISO 7789. The volume flow is adjusted by a flow is fed into the return flow system in a cost load. The screw-in cartridge is suitable for in-
Wandfluh proportional solenoid (VDE standard saving manner, and as a result, prevents an stallation in control blocs.
0580). The cartridge body is made of steel. A overheating of the hydraulic system. The po-
special surface treatment guarantees a good wer controlled, proportional solenoid running
protection against corrosion and wear as well in oil acts directly on the throttle spool, which
as very good low-friction characteristics of the opens the throttle segments in the cartridge
pressure compensating- and throttle spool. body. Proportional to the current demand of the
The solenoid coil is zinc- / nickel-coated. proportional solenoid, the throttle aperture
changes, and with this the volume flow. In case
of a current-free solenoid, the throttle spool is
held in closed position by a spring. For driving
the valve, Wandfluh proportional amplifiers are
available (see Register 1.13).

TYPE CODE
Q D P PM42 - 160 - / W - #
Flow control valve
3-way
Proportional
Screw-in cartridge M42 x 2
160 l/min
Nominal volume flow rate Q N
12 VDC G12
Nominal voltage U N
24 VDC G24
without coil X5
Slip-on coil 10 Metal housing, round M42x2
69 20 s41 3 (A) 2 (T)
Connection execution Connector socket EN 175301-803 / ISO 4400 D
15 Connector socket AMP Junior-Timer J
Connector Deutsch DT04-2P G
1 (P)
Sealing material NBR
32 FKM (Viton) D1
Manual override Screwed sealing plug HB0
Manual emergency actuation HC8.5
17 50 80 60 90 70
Design-Index (Subject to change)
1 88
138 90
229

SYMBOLS GENERAL SPECIFICATIONS
simplified detailed Description 3-way proportional flow control valve
Construction Screw-in cartridge for cavity acc. to ISO 7789
Operation Proportional solenoid
Mounting Screw-in thread M42 x 2
Ambient temperature -20…70 °C
1 3 Mounting position any
1 3 Fastening torque M = 100 Nm for screw-in cartridge
D
2 M = 5 Nm for knurled nut
D
Weight m = 2,34 kg
Flow direction see symbol
2

Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 2.6-695E 1/3
CH-3714 Frutigen Edition 15 08
