Module typ manifold system
T T T T T T Module type manifold systems Module type manifold systems
A B A B A B
diMensions
Block for parallel circuit Module type manifold blocks
BLV4P • p max = 350 bar NG6
Ø 20.5 G 1/4“ 9.5 ISO 4401-03
31.5 G 1/4“ Ø 8.5
P T 2
10
DESCRIPTION FUNCTION APPLICATION
T A B
B A M5 Module type manifold blocks with interface The module type manifold blocks are available This block system can be used as a replace-
14 27 44 NG6 acc. to ISO 4401-03. Using an adapter with 3 different basic circuits, namely parallel, ment for expensive special blocks. Existing
P plate and connecting blocks, combinations serial and pressure reduction circuit. systems may be exended or reduced by adding
21 21 with NG3-Mini, NG4-Mini and NG10 are also as removing modular blocks.
possible (see also data sheet 2.9-80). The
P T module type manifold blocks are made from
64 12 steel and are zinc-nickel coated.
38
Block for serial circuit 50
BLV4S
T1 T
TYPE CODE
T A B A LV 6 #
B A
International standard interface ISO
P
Module type manifold
Nominal size 6
P T
Type list
Block for pressure reduction circuit Parallel circuit P
BLV4D Pressure reduction circuit D
Pred T
Design-Index (Subject to change)
T A B
B A
P
GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS
Description Parallel- and pressure reduction circuit Working pressure p max = 350 bar
P T Nominal size NG6 acc. to ISO 4401-03
Fastening see data sheet 2.9-124
Intermediate block Connection Threaded connections
BLV4Z P, P T1, A, B = G3/8“
T red = G1/2“
Mounting position any
12
Weight: m = 2,0 kg
64 50
SYMBOLS
50
27 Block for parallel circuit Block for pressure reduction circuit
ALV6P ALV6D
parts list
Pred
P P P T1 P P T1 P Pred
Position Article Description
10 160.2155 O-ring ID 15,54x2,62 T T T T T T T T T T
36
25 24 A B A A B B A A B B A B
15
accessories
8 Fixing brakets BB41/ BB42 and studs
56
see data sheet 2.9-122

Ø 28.5 G 3/8“ Ø 28.5 G 3/8“ 9.5
9.5
G 3/8“ G 1/2“ G 3/8“ Ø 10.5 G 1/2“ Ø 10.5
