P. 1298

Proportional flow control valve                                                                                              Proportional flow control valve
                                                                               Proportional flow control valve


       SYMBOL                                              ACTUATION                                                               PERFORMANCE SPECIFICATIONS
       Simplified               Detailed QN…                Actuation          Proportional solenoid, wet pin push                 Oil viscosity u = 30 mm /s
                                                                                                                                                    2
            2                                 2                                type, pressure tight                                 Q = f (I)  Volume flow signal characteristics        Q = f (p)  Volume flow pressure characteristics
                                                            Execution          W.S45 / 23 x 50 (Data sheet 1.1-180)                     Q [l/min]                                           Q [l/min]
                                                                               M.S45 / 23 x 50 (Data sheet 1.1-181)                  100  K0978                                           100  K0979
                                                            Connection         Connector socket EN 175301 – 803                                                             Q  = 80 l/min
                                                                                                                                                                             N
            1                                                                                                                         80                                    Q  = 63 l/min  80                                   Q = 80 l/min
                                                                                                                                                                                                                                 N
                                                                               Connector socket AMP Junior-Timer                      60                                     N             60                                   Q  = 63 l/min
                                                                               Connector Deutsch DT04 – 2P                                                                                                                       N
                                                                                                                                      40                                    Q N  = 32 l/min  40
                                                                                                                                                                                                                                Q  = 32 l/min
                                                                                                                                      20                                                   20                                    N
                                                                                                                                       0                                                    0
                                                                                                                                         0   10  20  30  40 50 60 70 80 90  100 I  [%]        0   50  100  150  200  250  300  350 p [bar]

                                              1
                                                                                                                                    Q  = f (p)  Leakage volume flow characteristics
                                                                                                                                     L
                                                                                                                                        Q [cm /min]
                                                                                                                                            3
                                                                                                                                     400  K0980
       GENERAL SPECIFICATIONS                              HYDRAULIC SPECIFICATIONS                                                  300

       Designation        Proportional 2-way flow control valve  Working pressure  p  = 350 bar                                      200
                                                                                max
       Construction       Direct operated                   Maximum volume flow  Q  = 80 l/min
                                                                                max                                                  100
       Mounting           Screw-in cartridge construction   Minimum volume flow  Q  = 0,2 l/min
                                                                                min
       Nominal size       1  ⁄16 “-12 UN according to Wandfluh   Volume flow direction  1 → 2                                          0  0  50   100  150  200  250  300  350 p [bar]
                           5
                          standard                          Leakage oil        See characteristics
       Actuation          Proportional solenoid             Nominal volume flow   Q  = 32; 63; 80 l/min
                                                                                N
       Ambient temperature  -25…+70 °C                      range
       Weight             0,95 kg                           Hysteresis         ≤ 5 % at optimal dither signal
       MTTFd              150 years                         Fluid              Mineral oil, other fluid on request
                                                            Viscosity range    12 mm /s…320 mm /s
                                                                                            2
                                                                                   2
                                                            Temperature range   -25…+70 °C (NBR)                                   ACCESSORIES                                          SURFACE TREATMENT
                                                            fluid              -20…+70 °C (FKM)                                     Proportional amplifier           Register 1.13       ◆  The cartridge body is gas-nitro-carburised
                                                            Contamination      Class 18 / 16 / 13                                   Electric plug B (black)          Article no. 219.2002  ◆  The armature tube and the slip-on coil are zinc- / nickel-coated
                                                            efficiency                                                              Technical explanations           Data sheet 1.0-100
                                                            Filtration         Required filtration grade ß 6…10 ≥ 75,               Filtration                       Data sheet 1.0-50
                                                                               see data sheet 1.0-50
                                                                                                                                                                                        SEALING MATERIAL
                                                                                                                                                                                        NBR or FKM (Viton) as standard, choice in the type code






       MANUAL OVERRIDE                                     ELECTRICAL SPECIFICATIONS                                               INSTALLATION NOTES                                   STANDARDS
       HB4,5                                                Protection class   Connection execution D: IP65                         Mounting type      Screw-in cartridge 1  ⁄16 “-12 UN  Cartridge cavity   ISO 7789
                                                                                                                                                                      5
       Optionally: Screw plug (HB0), no actuation possible                     Connection execution J: IP66                         Mounting position  Any, preferably horizontal        Solenoids           DIN VDE 0580
                                                                               Connection execution G: IP67 and IP69K               Tightening torque  M  = 80 Nm Screw-in cartridge     Connection execution D  EN 175301 – 803
                                                                                                                                                        D
                                                            Relative duty factor  100 % DF                                                             M  = 5 Nm knurled nut             Protection class    EN 60 529
                                                                                                                                                        D
                                                            Standard nominal   12 VDC, 24 VDC                                                          M  = 9,5 Nm HB0                   Contamination efficiency  ISO 4406
                                                                                                                                                        D
                                                            voltage                                                                                    M  = 5,5 Nm HB4,5
                                                                                                                                                        D
                                                            Limiting current at  I  = 1560 mA (U  = 12VDC)
                                                                                          N
                                                                               G
                                                            50 °C              I  = 780 mA (U  = 24VDC)
                                                                                         N
                                                                               G
                                                           Note!    Other electrical specifications see data sheet 1.1-180
                                                                    (slip-on coil W) and 1.1-181 (slip-on coil M)



                         www.wandfluh.com  Illustrations are not binding  Data subject to change  2/4  Edition: 22 16  2.6-675 E                      www.wandfluh.com  Illustrations are not binding  Data subject to change  3/4  Edition: 22 16  2.6-675 E
