Threaded subplate Threaded subplate
Subplate

DIMENSIONS Threaded subplate
AG6S AG6U Installation in pipes NG10
30 30 ISO 4401-05
76 23 7 76 23 7 ◆ p = 350 bar
max
5.5 9.5 5.5 9.5
T ◆ Connections G1/2“

T

T T
A B
A A B B A B
60 46 60 46
M5 M5
G3/8"
P P
9.5 P 9.5 DESCRIPTION SYMBOL
P Threaded subplate with mounting interface for vertical stacking and
90 G3/8" 90

threaded connection of the connections A, B, P, T.
AG6SU HYDRAULIC CONNECTION
90 38 A P T B
76 31 7
5.5 9.5 17.8

T T
T
A B TYPE CODE
31 21 32.5
60 29 A B 46 A G 10 #
G 3/8" International standard interface ISO
P M5 P
P 9.5 21.5
A B 40.5 Threaded subplate
40 25

Nominal size 10
Type list
Connections A, B, P, T on the side S
Connections A, B, P, T at the bottom U
Connections A, B, on the side and P, T at the bottom SU
Design index (subject to change)
2.9-40

GENERAL SPECIFICATIONS INSTALLATION NOTES
Designation Threaded subplate Mounting type 4 fixing holes for M10
Mounting Installation in pipes Mounting position Any
Nominal size NG10 according to ISO 4401-05 Threaded connections G1/2“ in A, B, P, T
Weight 3,65 kg (AG10S)
3,75 kg (AG10U)
3,70 kg (AG10SU)

SURFACE TREATMENT
◆ The plates made of steel are zinc-nickel coated

Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 sales@wandfluh.com

www.wandfluh.com Illustrations are not binding Data subject to change 2/2 Edition: 21 29 2.9-30 E www.wandfluh.com Illustrations are not binding Data subject to change 1/2 Edition: 21 29 2.9-40 E
