Proportional flow control valve Proportional flow control valve
Proportional flow control valve

SYMBOL PERFORMANCE SPECIFICATIONS
Simplified Detailed QN… Detailed QO… Oil viscosity u = 30 mm /s
2
2 2 2 Q = f (I) Volume flow signal characteristics QN Q = f (I) Volume flow signal characteristics QO

Q [l/min] Q [l/min]
100 K0978 80 K4164
Q = 80 l/min
N
1 80 Q = 63 l/min 70
60 N 60
50
40 Q N = 63 l/min
40 Q N = 32 l/min 30
20 20
10 Q N = 32 l/min
0 0
0 10 20 30 40 50 60 70 80 90 100 I [%] 0 10 20 30 40 50 60 70 80 90 100 I [%]

1 1
Q = f (p) Volume flow pressure characteristics QN + QO Q = f (p) Leakage volume flow characteristics QN + QO
I = I G L Q [cm /min]
3
Q [l/min] 400 K0980
GENERAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS 100 K0979 300
Designation Proportional 2-way flow control valve Working pressure p = 350 bar 80 Q = 80 l/min
N
max 200
Construction Direct operated Maximum volume flow Q = 80 l/min 60 Q = 63 l/min
N
max
Mounting Screw-in cartridge construction Volume flow direction 1 → 2 40 100
Q N = 32 l/min
Nominal size M33 x 2 according to ISO 7789 Leakage oil See characteristics 20 0
Actuation Proportional solenoid Nominal volume flow Q = 32 l/min, 63 l/min, 80 l/min (QN) 0 0 50 100 150 200 250 300 350 p [bar]
N
Ambient temperature -25…+70 °C range Q = 32 l/min, 63 l/min (QO) 0 50 100 150 200 250 300 350 p [bar]
N
Weight 0,95 kg Hysteresis ≤ 6 % (QN); 10 % (QO)
MTTFd 150 years at optimal dither signal
Repeatability ≤ 2 % at optimal dither signal
Fluid Mineral oil, other fluid on request ACCESSORIES SURFACE TREATMENT
Viscosity range 12 mm /s…320 mm /s Flange body / sandwich plate Data sheet 2.6-680 ◆ The cartridge body is gas-nitro-carburised
2
2
The armature tube and the slip-on coil are zinc- / nickel-coated
MANUAL OVERRIDE Temperature range -25…+70 °C (NBR) Threaded body Data sheet 2.9-205 ◆
fluid
-20…+70 °C (FKM)
HB4,5 Proportional amplifier Register 1.13
Optionally: Screw plug (HB0), no actuation possible Contamination Class 18 / 16 / 13 Mating connector black (B) Article no. 219.2002
efficiency SEALING MATERIAL

Filtration Required filtration grade ß 6…10 ≥ 75, Technical explanations Data sheet 1.0-100 NBR or FKM (Viton) as standard, choice in the type code
see data sheet 1.0-50 Filtration Data sheet 1.0-50
Relative duty factor Data sheet 1.1-430

ACTUATION ELECTRICAL SPECIFICATIONS
INSTALLATION NOTES STANDARDS
Actuation Proportional solenoid, wet pin push Protection class Connection execution D: IP65
type, pressure tight Connection execution J: IP66 Mounting type Screw-in cartridge M33 x 2 Cartridge cavity ISO 7789
Execution W.S45 / 23 x 50 (Data sheet 1.1-180) Connection execution G: IP67 and IP69K Mounting position Any, preferably horizontal Solenoids DIN VDE 0580
M.S45 / 23 x 50 (Data sheet 1.1-181) Relative duty factor 100 % DF Tightening torque M = 80 Nm Screw-in cartridge Connection execution D EN 175301 – 803
D
Connection Connector socket EN 175301 – 803 Standard nominal 12 VDC, 24 VDC M = 5 Nm knurled nut Protection class EN 60 529
D
Connector socket AMP Junior-Timer voltage Contamination efficiency ISO 4406
Connector Deutsch DT04 – 2P Limiting current at I = 1560 mA (U = 12VDC)
N
G
50 °C I = 780 mA (U = 24VDC)
G
N
Note! Other electrical specifications see data sheet 1.1-180
(slip-on coil W) and 1.1-181 (slip-on coil M)

www.wandfluh.com Illustrations are not binding Data subject to change 2/4 Edition: 20 41 2.6-651 E www.wandfluh.com Illustrations are not binding Data subject to change 3/4 Edition: 20 41 2.6-651 E
