Proportional throttle valve
Proportional throttle valve

Proportional throttle cartridge with integrated
electronics M33 x 2
◆ direct operated ISO 7789
◆ Q = 65 l/min
max
◆ Q N max = 63 l/min
◆ p = 350 bar
max

DESCRIPTION APPLICATION
Direct operated proportional throttle valve with integrated electro- Proportional throttle valves with integrated electronics are perfec-
nics as screw-in cartridge for cavity according to ISO 7789. With tly suitable for demanding applications in which the volume flow
the solenoid deenergised, the control spool is held in the closed frequently has to be changed. They are used in applications where
position by a spring. The change of the electric current is followed high valve-to-valve reproducibility, easy installation, comfortable
by a proportional volume flow change. Progressive increase and operation and high precision are very important. The integrated
decrease of volume flow and reduced hysteresis are characte- controller reliefs the machine control and operates the volume flow
ristics of this valve. The Plug & Play valves are factory set and ad - control in a closed loop circuit. The applications are in the indust-
justed and have therefore a high valve-to-valve reproducibility. The rial as well as in the mobile hydraulics for the smooth control of
control takes place via an analogue interface or a fieldbus interface hydraulic actuations. The screw-in cartridge is perfectly suitable
(CANopen, J1939 or Profibus DP). The parameterisation takes pla- for installation in control blocks and is installed in sandwich-
ce by means of the free of cost parameterisation and diagnostics (vertical stacked systems) and in flange plates (corresponding data
software «PASO» or via fieldbus interface. The USB parameterisa- sheets in this register). For machining the cartridge cavity in steel
tion interface is accessible through a screw plug. As an option, and aluminum blocks, cavity tools are available (hire or purchase).
these valves are available with integrated controller. As feedback Please refer to the data sheets in register 2.13.
value generators sensors with voltage or current output can be Note! „PASO” is a Windows programm in the flow diagram
connected directly. The available controller structures are optimi - style, which enables the intuitive adjustment and storing
sed for applications with hydraulic actuations. of all variable parameters. The data remain saved in
case of a power failure and can also be reproduced and
transferred to other DSV.

SYMBOL ACTUATION
„normally closed” DN Actuation Proportional solenoid, wet pin push
2 type, pressure tight
Connection Via device receptacle

1

MANUAL OVERRIDE ELECTRICAL SPECIFICATIONS
HB4,5 as standard
Protection class IP67 with suitable mating connector and
closed housing cover
Ramps Adjustable
Parameterisation Via fieldbus or USB
Supply voltage 12 VDC, 24 VDC

Note! Exact electrical specifications and detailed description
of «DSV» electronics can be found on data sheet
1.13-76.

www.wandfluh.com Illustrations are not binding Data subject to change 1/6 Edition: 22 46 2.6-561 E
