MODULAR TECHNOLOGY

The modular construction of system solutions makes it possible to implement solutions
for several consumers by the simple stringing together of valve stations. For this purpose,
existing valve functions are stacked on top of each other in a vertical chain. For each con-
sumer, all required functions such as pressure relief, protection and actuation by means
of switching or proportional valves can be combined according to the individual require-
ments. This allows for the construction of very compact control systems.

MULTI-STATION SUBPLATE WITH SANDWICH CHARACTERISTICS
CONSTRUCTION The multi-station subplate serves as a basic element for
ready-to-connect controls in a vertical stacking construction.
It supplies up to eight valve stations. Only one connection for
the pressure supply and one tank connection is required. Each
station has two outputs for the connection of a consumer.
FEATURES
• Compact hydraulic controls
• Individual valve functions with vertical stacking
• Modular solutions
• Flange and intermediate plates for switching and propor-
tional valves
• One common tank and pump line
• Separate consumer connections per station
• Easy mounting
• Nominal sizes NG3, NG4, NG6, NG10

HORIZONTAL MOUNTING SYSTEM CHARACTERISTICS
Enables a simple modular construction of valve controls for
any number of consumers. Particularly in power unit con-
struction, the system can be very easily built up on a basic
block and expanded with a variety of valve functions.

FEATURES
• Compact hydraulic controls
• Individual valve functions with vertical stacking
• Modular construction and combinable with customer-spe-
cific modules
• Parallel and series circuits can be flexibly combined
• Flange and intermediate plates for switching and propor-
tional valves
• One common tank and pump line
• Separate consumer connections per station
• Easy to expand later on
• Nominal sizes NG3, NG4, NG6, NG10
